WI0200

19-strand Nickel-Chrome Iron Core Wire (60/15)

Nickel-Chrome 60/15 is essential for resistor elements in high temperature applications and operates at temperatures up to 1000°C.  This wire has 19 strands and can be used in our Flexible Ceramic Pad Heaters and Flexible Insulated Preheaters.  Each roll has 500m length of wire.

  • Dimensions of Roll: 197 H x 248 W x 248 D mm
  • Length of Wire: 500m
  • Weight: 13kg
  • Materials: 60% Nickel, 15% Chrome, 25% Iron
  • Wire Diameter: 2.83mm
  • Maximum Working Temperature: 1000°C
  • No. of Strands: 18 x 0.52mm + 1 x 0.6mm, 19 strands twisted together
1 pc
Cables & Wires

A variety of cables and wires are used throughout the heat treatment process; either for thermocouples/temperature control or recording, or to supply electrical energy throughout the circuits.

Nickel-Chrome wires and Nickel Cold Tail wire come in rolls of 500m while the Thermocouple Wires, Heater Distribution Cables and Compensating Cables all come in rolls of 100m.

4-bank Nickel-Chrome Iron Wire is supplied with 10pc per set whilst Splitter Cables and Triple Cable Sets are supplied in 1m and 30m lengths respectively.
